Stainless Steel Impeller and Turbine Component

This impeller and turbine component is intended to match the interfaces defined by the equipment assembly drawing. This impeller and turbine component is specified in Stainless Steel.

Technical Overview

• Part: Impeller and Turbine Component
• Material: Stainless Steel

Impeller and Turbine Component Design and Assembly

• Vane and rim geometry: show the flow-related profile, outside diameter and direction of rotation.
• Hub connection: define the shaft bore, keyway or other attachment features present in the design.
• Assembly controls: specify clearances, reference datums and any balance requirement separately.

Material and Manufacturing Requirements

The specified material is stainless steel. State the exact grade and delivery condition when requesting a quotation, particularly where the material must match an existing assembly or a defined service requirement.

The manufacturing route should be agreed against the finished geometry and order quantity. Identify the surfaces and mating features that govern acceptance rather than specifying processes that are not required by the design.

Quotation Information

Provide a dimensioned part drawing showing the assembly interfaces, required material and the surfaces that determine fit. Include the drawing revision, required quantity and any sample or inspection documentation needed for approval.
