Stainless Steel Butterfly Valve

A butterfly valve part whose disc, stem and body interfaces must match the selected valve assembly. This butterfly valve is specified in Stainless Steel.

Technical Overview

• Part: Butterfly Valve
• Material: Stainless Steel

Butterfly Valve Design and Assembly

• Disc relationship: identify the mating disc and body clearance required by the valve design.
• Stem connection: define shaft alignment, attachment features and operating interfaces.
• Sealing arrangement: specify the relevant contact surfaces and the seal design used in the complete assembly.

Material and Manufacturing Requirements

The specified material is stainless steel. State the exact grade and delivery condition when requesting a quotation, particularly where the material must match an existing assembly or a defined service requirement.

The manufacturing route should be agreed against the finished geometry and order quantity. Identify the surfaces and mating features that govern acceptance rather than specifying processes that are not required by the design.

Quotation Information

Supply the disc or body drawing, shaft connection details and sealing requirements. Operating ratings must be agreed for the finished valve. Include the drawing revision, required quantity and any sample or inspection documentation needed for approval.
