Pressure Reducing Valve Connector

A connector for the interface between a valve and its adjoining connection. This pressure reducing valve connector is produced to the specified part drawing. The manufacturing specification includes precision machining.

Technical Overview

• Part: Pressure Reducing Valve Connector
• Processing: Precision Machined

Pressure Reducing Valve Connector Design and Assembly

• Two-sided interface: provide the dimensions of each mating end and identify the connected components.
• Location and orientation: show the reference features used to position the connector.
• Connection requirements: specify thread, sealing or retention details applicable to the selected design.

Material and Manufacturing Requirements

The material grade is to be defined with the order drawing. Identify the intended equipment and service environment so that the material requirement can be agreed before the manufacturing specification is finalized.

Precision machining is specified for this component. Identify the critical dimensions, their reference datums and the surfaces requiring a defined finish so the quotation reflects the functional requirements of the actual part.

Quotation Information

Confirm connection type, thread or bore dimensions, sealing arrangement and available assembly clearance. Include the drawing revision, required quantity and any sample or inspection documentation needed for approval.
