Cast Stainless Steel Base

A base item for the mounting arrangement identified in the equipment design. This base is specified in Stainless Steel. The manufacturing specification includes casting and precision machining.

Technical Overview

• Part: Base
• Material: Stainless Steel
• Processing: Precision Machined, Cast

Base Design and Assembly

• Seating surface: identify the face that supports or locates the adjoining assembly.
• Attachment coordinates: provide mounting-hole positions and the reference datums.
• Installation envelope: define overall dimensions and clearance to the surrounding structure.

Material and Manufacturing Requirements

The specified material is stainless steel. State the exact grade and delivery condition when requesting a quotation, particularly where the material must match an existing assembly or a defined service requirement.

Casting is specified for this part. Clarify the required casting geometry, the surfaces to be machined and any acceptance criteria relevant to the finished component rather than assuming a universal casting specification.

Precision machining is specified for this component. Identify the critical dimensions, their reference datums and the surfaces requiring a defined finish so the quotation reflects the functional requirements of the actual part.

Quotation Information

Define the seating surface, attachment-hole pattern and locating features used to position the adjoining assembly. Include the drawing revision, required quantity and any sample or inspection documentation needed for approval.
