Stainless Steel Shackle Component

A shackle item whose pin and body geometry must follow the specified drawing. This shackle component is specified in Stainless Steel. The manufacturing specification includes precision machining.

Technical Overview

• Part: Shackle Component
• Material: Stainless Steel
• Processing: Precision Machined

Shackle Component Design and Assembly

• Part geometry: provide a dimensioned drawing showing the complete outline and any functional internal features.
• Assembly interfaces: identify the mating parts, installation datums and dimensions that control fit.
• Order definition: specify the material, required surface condition and which features need particular inspection attention.

Material and Manufacturing Requirements

The specified material is stainless steel. State the exact grade and delivery condition when requesting a quotation, particularly where the material must match an existing assembly or a defined service requirement.

Precision machining is specified for this component. Identify the critical dimensions, their reference datums and the surfaces requiring a defined finish so the quotation reflects the functional requirements of the actual part.

Quotation Information

Provide opening dimensions, pin connection and material requirements. Any rated-load claim requires separate design and test documentation. Include the drawing revision, required quantity and any sample or inspection documentation needed for approval.
