Stainless Steel Actuating Sleeve

A sleeve item associated with the actuation mechanism used with this component. This actuating sleeve is specified in Stainless Steel.

Technical Overview

• Part: Actuating Sleeve
• Material: Stainless Steel

Actuating Sleeve Design and Assembly

• Guiding surfaces: specify bore and outside profiles in relation to the mating mechanism.
• Travel features: show the geometry used to transmit or limit movement.
• Locating details: define axial references and the fit of any retaining or adjoining components.

Material and Manufacturing Requirements

The specified material is stainless steel. State the exact grade and delivery condition when requesting a quotation, particularly where the material must match an existing assembly or a defined service requirement.

The manufacturing route should be agreed against the finished geometry and order quantity. Identify the surfaces and mating features that govern acceptance rather than specifying processes that are not required by the design.

Quotation Information

Specify bore fit, outside profile, travel-related features and locating surfaces. Include the mating-part drawing where needed. Include the drawing revision, required quantity and any sample or inspection documentation needed for approval.
