4-Axis Machined Investment-Cast Stainless Steel Motor Cover

A cover item for the mating housing or assembly specified for this component. This motor cover is specified in Stainless Steel. The manufacturing specification includes investment casting and 4-axis machining.

Technical Overview

• Part: Motor Cover
• Material: Stainless Steel
• Processing: 4-Axis Machined, Investment-Cast

Motor Cover Design and Assembly

• Outer profile: define the cover contour and its relationship to the adjoining housing.
• Attachment pattern: show locating features and fastening positions.
• Enclosed space: identify clearances, access openings and any contact-face requirements included in the design.

Material and Manufacturing Requirements

The specified material is stainless steel. State the exact grade and delivery condition when requesting a quotation, particularly where the material must match an existing assembly or a defined service requirement.

Investment casting is included in the specified route. Identify which features remain as cast and which require finishing so the casting requirements and final assembly dimensions can be reviewed together.

The specified route includes 4-axis machining. Define the angular relationship between machined features and identify the common datums used to locate features on different faces of the component.

Quotation Information

Define the outer profile, fastening locations and clearance to the enclosed components. Include any sealing-face requirements. Include the drawing revision, required quantity and any sample or inspection documentation needed for approval.
