Investment-Cast 316 Stainless Steel Metering Valve

A metering valve item whose internal geometry and connection dimensions depend on the specified flow-control assembly. This metering valve is specified in 316 Stainless Steel. The manufacturing specification includes investment casting and precision machining.

Technical Overview

• Part: Metering Valve
• Material: 316 Stainless Steel
• Processing: Precision Machined, Investment-Cast

Metering Valve Design and Assembly

• Component scope: identify the valve type and the exact part required within the assembly.
• Connection geometry: provide the dimensions of the mating parts and the appropriate connection standard.
• Service-related details: state the intended fluid and operating conditions where they affect the specified material or design.

Material and Manufacturing Requirements

The specified material is 316 Stainless Steel. Include the applicable grade designation and delivery condition in the drawing or purchase specification, together with any material documentation required for the order.

Investment casting is included in the specified route. Identify which features remain as cast and which require finishing so the casting requirements and final assembly dimensions can be reviewed together.

Precision machining is specified for this component. Identify the critical dimensions, their reference datums and the surfaces requiring a defined finish so the quotation reflects the functional requirements of the actual part.

Quotation Information

Provide the metering passage drawing, adjustment interface and service conditions. Flow characteristics require confirmation for the assembled valve. Include the drawing revision, required quantity and any sample or inspection documentation needed for approval.
