Investment-Cast Stainless Steel Pressure Plate

A pressure-plate item for the specified clamping or mechanical arrangement. This pressure plate is specified in Stainless Steel. The manufacturing specification includes investment casting and machining.

Technical Overview

• Part: Pressure Plate
• Material: Stainless Steel
• Processing: Machined, Investment-Cast

Pressure Plate Design and Assembly

• Contact faces: identify the surfaces that transfer clamping or assembly contact.
• Mounting pattern: provide the center opening and fastening geometry.
• Plate dimensions: specify thickness and any flatness or parallelism requirements on the drawing.

Material and Manufacturing Requirements

The specified material is stainless steel. State the exact grade and delivery condition when requesting a quotation, particularly where the material must match an existing assembly or a defined service requirement.

Investment casting is included in the specified route. Identify which features remain as cast and which require finishing so the casting requirements and final assembly dimensions can be reviewed together.

Machining is included in the part specification. The drawing should distinguish functional interfaces from general surfaces and identify the dimensions that must be coordinated with the adjoining components.

Quotation Information

Define contact faces, center opening, fastening pattern and thickness. Specify flatness or parallelism requirements where they affect assembly. Include the drawing revision, required quantity and any sample or inspection documentation needed for approval.
