Hex Pipe Fitting

A pipe fitting with the hexagonal feature stated in the product name. This hex pipe fitting is produced to the specified part drawing. The manufacturing specification includes precision machining.

Technical Overview

• Part: Hex Pipe Fitting
• Processing: Precision Machined

Hex Pipe Fitting Design and Assembly

• End connections: identify the thread, tube, weld or other connection types actually required.
• Flow opening: specify bore dimensions and the relationship between the two ends.
• Installation features: define wrenching flats, orientation and the space available for assembly.

Material and Manufacturing Requirements

The material grade is to be defined with the order drawing. Identify the intended equipment and service environment so that the material requirement can be agreed before the manufacturing specification is finalized.

Precision machining is specified for this component. Identify the critical dimensions, their reference datums and the surfaces requiring a defined finish so the quotation reflects the functional requirements of the actual part.

Quotation Information

Confirm wrench-flat dimensions, bore size, thread designation and the sealing interface at each end. Include the drawing revision, required quantity and any sample or inspection documentation needed for approval.
