Pump Impeller

An impeller item for a rotating pump assembly. This pump impeller is produced to the specified part drawing. The manufacturing specification includes precision machining.

Technical Overview

• Part: Pump Impeller
• Processing: Precision Machined

Pump Impeller Design and Assembly

• Vane and rim geometry: show the flow-related profile, outside diameter and direction of rotation.
• Hub connection: define the shaft bore, keyway or other attachment features present in the design.
• Assembly controls: specify clearances, reference datums and any balance requirement separately.

Material and Manufacturing Requirements

The material grade is to be defined with the order drawing. Identify the intended equipment and service environment so that the material requirement can be agreed before the manufacturing specification is finalized.

Precision machining is specified for this component. Identify the critical dimensions, their reference datums and the surfaces requiring a defined finish so the quotation reflects the functional requirements of the actual part.

Quotation Information

Provide the vane geometry, outside diameter, hub bore and shaft attachment. Balance requirements and rotation direction should be stated for the final part. Include the drawing revision, required quantity and any sample or inspection documentation needed for approval.
