Stainless Steel Hex Pipe Fitting

A pipe fitting with the hexagonal feature stated in the product name. This hex pipe fitting is specified in Stainless Steel. The manufacturing specification includes precision machining.

Technical Overview

• Part: Hex Pipe Fitting
• Material: Stainless Steel
• Processing: Precision Machined

Hex Pipe Fitting Design and Assembly

• End connections: identify the thread, tube, weld or other connection types actually required.
• Flow opening: specify bore dimensions and the relationship between the two ends.
• Installation features: define wrenching flats, orientation and the space available for assembly.

Material and Manufacturing Requirements

The specified material is stainless steel. State the exact grade and delivery condition when requesting a quotation, particularly where the material must match an existing assembly or a defined service requirement.

Precision machining is specified for this component. Identify the critical dimensions, their reference datums and the surfaces requiring a defined finish so the quotation reflects the functional requirements of the actual part.

Quotation Information

Confirm wrench-flat dimensions, bore size, thread designation and the sealing interface at each end. Include the drawing revision, required quantity and any sample or inspection documentation needed for approval.
